Nimu di mudellu: LA103DV1-SL01
10.3 Inch Lg mostra La103DV1-Sl01 Bulghness Alta 650nits TFT Panel LCDL LULIKL.
U listessu Modellu di dimensione: La103wf3-sl01
| brand | LG Display (LG Display) | Model name | LA103DV1-SL01 |
| size | 10.3 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution | 1280(RGB)×480 DVGA 133PPI | Pixel configuration | RGB vertical bar |
| Display size | 243.84×91.44(H×V) mm | Surface treatment | |
| Brightness(cd/m²) | 650 cd/m² (Min.) or customized | contrast | 1000:1 (Min.) (TM) |
| Viewing Angle | 89/89/89/89 (Min.)(CR≥10) | Appearance of size | 257.7×126.3×20.9(H×V×D)mm |
| Signal system | 50 pins LVDS (1 ch, 8-bit) , FPC | ||
| Maximum rated | Storage temperature: -40 ~ 90 °C Working temperature: -40 ~ 85 °C Vibration resistance: 3.0g (29.4m /s²) |
